Are you setting up stalls over concrete, trying to cut bedding costs, or wondering whether mats would make your horse more comfortable?
Before spending a few hundred dollars per stall, here’s how to decide whether you need mats, choose the right ones, and install them properly.
Table of Contents
Do Horses Need Mats in Their Stalls?
Not always, but they help in a lot of barns. Whether they’re worth it depends mostly on what’s under them. A bare concrete stall floor is hard, cold, and slick when wet, and a horse may not want to lie down on it. Wood floors soak up urine and start to smell. A textured mat can improve footing over either one, as long as it fits tightly over a sound, level base.
Dirt and clay floors are different. They’re softer to stand on, so a mat isn’t as necessary for comfort. The trouble is that horses dig holes in them, and urine leaves wet spots you’ll keep filling with fresh clay. A mat keeps the horse from digging into the floor and saves you that work.
Mats also make cleaning easier, since manure and wet bedding come off a flat surface instead of mixing into the dirt. Urine still gets through the seams, though, so the base needs to drain or the mats will start to smell underneath. Penn State Extension’s guide to stable flooring materials and drainage lists the downsides, too. Mats are expensive, they’re heavy to move, they can hold odors, and a fork can cut them. They also won’t absorb urine the way bedding does.
What Are Horse Stall Mats Made Of?
Most horse stall mats are rubber, usually made from recycled tires. Vulcanized rubber is cured to make it stronger and more resistant to moisture, which makes it easier to clean and disinfect. The Tractor Supply mat in the cost section below, for example, is 100% recycled vulcanized rubber. According to Greatmats, non-vulcanized rubber mats may need to be thicker to hold up as well and can soak up liquid if you power-wash them.
Other options include:
- EVA foam: Much lighter and easier to carry, but check what the product is made for. A general-purpose foam tile isn’t a substitute for a heavy-duty stall mat.
- Perforated rubber: Has holes for water to drain through, so it’s mostly used in wash racks.
- Poured or seamless systems: Rubber or urethane flooring installed as one surface with no seams. Get an installed quote before you compare it with loose mats.
Surface texture matters, too. Penn State recommends a rippled or bumped top for traction, since smooth rubber gets slippery when it’s wet, and a grooved underside to help carry urine away. Grooves only help if the floor underneath can handle the moisture, though. A mat is just the top layer of the stall floor, and the base and drainage under it matter just as much. If you’re still weighing your options, my guide to horse barn flooring for stalls and aisles compares them. New rubber mats often have a strong smell at first, so give them some time to air out in a well-ventilated space.
Horse Stall Mat Sizes
The standard horse stall mat is 4 by 6 feet, and it’s the size you’ll find stacked at most feed and farm stores. Each one covers 24 square feet, so divide the stall’s square footage by 24 and round up for a starting count. Then work out the layout, because some stall sizes mean cutting mats and using the pieces. Here’s how that works out for common horse stall sizes:
| Stall size | Square feet | 4×6 mats to buy |
|---|---|---|
| 10 x 10 ft | 100 | 5, with cutting |
| 10 x 12 ft | 120 | 5, with cutting |
| 12 x 12 ft | 144 | 6, no cutting in an exact-size stall |
| 12 x 14 ft | 168 | 7, with cutting |
| 12 x 16 ft | 192 | 8, no cutting in an exact-size stall |
These counts assume the stall matches the listed dimensions and has square corners. In a 10-by-12, four whole mats cover an 8-by-12 area, and you cut the fifth lengthwise into two 2-by-6 strips to fill the last 2 feet. A 10-by-10 is similar, except the four mats get trimmed to 4 by 5 feet and the fifth is cut into two 2-by-5 strips. Measure your stall wall to wall before you buy, and allow for posts or anything else in the way. Some companies also sell interlocking kits sized to cover a whole stall.
Horse Stall Mat Thickness
Penn State lists 1/2 to 3/4 inch as the most common thickness range, and 3/4 inch is a good starting point for a horse stall. A 4-by-6 mat that thick can weigh around 100 pounds. The Tractor Supply mat weighs 94, so plan how you’ll unload and move the mats before you buy. Thinner mats cost less and are easier to handle, but how well any mat stays flat also depends on the base, the fit, and the quality of the rubber.
You’ll also find thicker mats, but don’t choose on thickness alone. Check the surface texture, weight, warranty, and whether the mat is made for horse stalls. A thicker mat still doesn’t replace the bedding your horse needs.
How Much Do Horse Stall Mats Cost?
Prices vary by store and region, so check locally before you budget. As one example, Tractor Supply’s online listing for its 4-by-6-foot, 3/4-inch rubber stall mat showed $63.99 in October 2026. At that price, the six mats for a 12-by-12 stall come to about $384, not counting tax, delivery, or any base work. Matting a 10-by-12 stall with five mats would be about $320.
Interlocking kits and seamless poured floors cost more. Delivery can add a lot too, since you’re hauling several hundred pounds of rubber per stall. Penn State suggests shopping around on both the mats and the delivery, and comparing warranties while you’re at it.
Interlocking vs. Straight-Edge Stall Mats
Straight-edge mats are the standard 4-by-6 pieces laid side by side. They’re usually the lower-cost option and easy to replace one at a time. The downside is the seams. Shavings and urine work down between the mats, and over time they can push the mats apart or lift an edge. Penn State notes that horses can lift up areas that aren’t properly secured.
Interlocking mats have puzzle-style edges that hold the pieces together, so seams don’t open up as easily. They cost more, though, and they won’t fix a bad base. They still need a level surface to lock together and stay flat. If you’re covering a whole stall wall to wall, tightly fitted straight-edge mats can work well. If your mats keep shifting, interlocking edges may help, but check the base and fit first.
How to Install Horse Stall Mats
Even a good mat won’t sit flat on an uneven base. Check the manufacturer’s instructions for your mats, then follow these steps:
- Line up help. At about 100 pounds each, mats are a two-person job, and they’re floppy and awkward to grab. A hand truck or dolly helps, and a pair of locking pliers clamped to an edge gives you a handle.
- Prepare the base. It needs to be firm, level, and well compacted. Penn State describes mats going over concrete or 4 to 5 inches of compacted road base mix, but the right setup depends on your existing floor, soil, and drainage. Soft spots will show up later as dips and rocking mats.
- Plan for drainage. Urine will get through the seams, so the base shouldn’t hold moisture against the underside of the mat.
- Lay out the mats. Check which side the manufacturer says goes up. Some mats can go either way, depending on whether you want more traction or more drainage and cushion. Keep adjoining edges close with no raised edges, since Penn State warns that bedding caught in the seams can push mats apart.
- Cut to fit. Dense 3/4-inch rubber is hard to cut, so follow the manufacturer’s directions. Some owners use a sharp utility knife and a straightedge, scoring several passes and bending the mat open along the line as they go. Depending on the mat, another tool may be safer and easier. Cut away from yourself and take your time.
Do You Still Need Bedding Over Stall Mats?
Yes. Mats don’t replace bedding. You may need less of it for cushion, but still use enough to absorb urine, keep your horse clean and dry, and give him a comfortable place to lie down. And because horses can’t dig through a mat, your bedding doesn’t get mixed with dirt. Pine shavings, straw, and pellets all work over mats, and the best type of bedding for a horse stall depends on your horse, your budget, and what you can get locally.
For cleaning, pick out manure and wet spots daily as usual. Every so often, pull the bedding back, sweep the mats, and check the seams. How often you lift the mats depends on your drainage and the base. If you notice a smell or moisture coming up through the seams, lift them, let the base dry out, and clean and disinfect both sides before putting them back.
Stall mats are worth the money when they solve a problem you actually have, like a hard concrete floor, a horse that digs holes, or bedding disappearing into the dirt. Get the base right, keep the seams clean, and use enough bedding to keep your horse comfortable.
